$8891-4 Piece/Pieces
$8795-9 Piece/Pieces
$859≥10Piece/Pieces
| Jenis pembayaran: | D/A,D/P,T/T,Western Union |
| Inkoterm: | EXW |
| Transportasi: | Ocean,Land |
| Pelabuhan: | SHANGHAI,QINGDAO,TIANJING |
Merek: Lundi
Industri Yang Berlaku: Hotel, toko garmen, toko bahan bangunan, toko perbaikan mesin, pabrik manufaktur, pabrik makanan & minuman, peternakan, ritel, toko makanan, toko cetak, pekerjaan konstruksi, energi & pertambangan, toko makanan & minuman, perusahaan periklanan,, Hotel, Toko Garmen, Toko Bahan Bangunan, Bengkel Mesin, Pabrik Manufaktur, Peternakan, Penggunaan Rumah, Eceran, Perusahaan periklanan, Energi & Pertambangan, Toko Makanan & Minuman
Lokasi Showroom: Tidak ada
Kondisi: Baru
Nama Merk: Lundi
Power Souce: Motor AC
Min. Tinggi Pengangkat: 90mm
Dimensi Keseluruhan: 50*160*1100 s/e/l (mm)
Jaminan: 1 tahun
Laporan Tes Mesin: Asalkan
Video Keluar-inspeksi: Asalkan
Garansi Komponen Inti: 1 tahun
Komponen Inti: Bejana tekan, Motor, lain, Bantalan, Gigi, Pompa, Gearbox, Mesin
Model: BDD15
Mode Kerja: Semi-listrik
Weight(with Battery): 400kg
Tinggi Angkat: 2000mm
Panjang Keseluruhan: 1860mm
Lebar Keseluruhan: 800mm
Sistem Kontrol Pengemudi: Ac
Masa Garansi: 1 tahun
Setelah Layanan Garansi: Dukungan online
Lokasi Layanan Lokal: Tidak ada
Layanan Purna Jual Disediakan: Dukungan online
Layanan Di Luar Garansi: Dukungan teknis video
Status: Baru
Tempat Asal: Cina, Jiangsu, Cina
Sumber Daya Listrik: Motor AC
Laporan Uji Mekanis: Disediakan
Inspeksi Pabrik Video: Disediakan
Jenis Pemasaran: Produk Biasa
Masa Garansi Komponen Inti: 1 tahun
Panjang Garpu: 1100 mm
Fork Width: 320-1030mm
Lebar Garpu: 320-1030mm
Sertifikasi: CE, CE
| Menjual unit | : | Piece/Pieces |
| Tipe paket | : | Film yang dibungkus, ekspor palet standar atau kotak kayu. Metode pengemasan spesifik dapat dibahas. |
| Contoh pada gamba | : |
|
The file is encrypted. Please fill in the following information to continue accessing it
|
Model |
|
BDD15 |
|
Working mode |
|
Electric |
|
Driving mode |
|
Walkie |
|
Rated load |
Q (kg) |
1500 |
|
Load centre distance |
c (mm) |
500 |
|
Front suspension |
x (mm) |
745 |
|
Wheel spacing |
Y (mm) |
1200 |
|
Weight (with battery) |
kg |
400 |
|
Wheels |
|
nylon |
|
Wheel size, front wheel |
|
Φ180*50 |
|
Wheel size, rear wheel |
|
Φ80×70 |
|
Wheel, front and rear number (x = drive wheel) |
|
2/2 |
|
Front wheel |
b10(mm) |
690 |
|
Rear wheel |
b11(mm) |
410/525 |
|
Lift height |
h1(mm) |
2000 |
|
Height of door frame retracted |
h3(mm) |
1590 |
|
Maximum height of gantry during operation |
h4(mm) |
2500 |
|
Lower height |
h13(mm) |
90 |
|
Overall length |
l1(mm) |
1860 |
|
Length of fork |
l2(mm) |
1100 |
|
Overall width |
b1(mm) |
800 |
|
Fork size |
S/e/l (mm) |
50×160×1100 |
|
Fork width |
b5(mm) |
320-1030 |
|
Distance center off clearance |
m2(mm) |
40 |
|
Channel width, tray 1000 x1200(1200 cross fork placement) |
Ast(mm) |
2305 |
|
Channel width, pallet 800 x1200(1200 placed along fork) |
Ast(mm) |
2258 |
|
Turning radius |
Wa(mm) |
1425 |
|
Speed up, full load/ no load |
m/s |
0.08/0.1 |
|
Drop speed, full load/ no load |
m/s |
0.15/0.12 |
|
Driving brake |
|
Mechanical braking |
|
Lift motor power |
kW |
2.2 |
|
Battery voltage/ rated capacity |
V/Ah |
12/120 |
|
Battery weight |
Kg |
43 |
|
Driver's Ear Noise Level DIN12053 |
dB (A) |
≤70 |
T1: Apakah Anda sebuah pabrik?
A1: Tentu saja.
