$8991-5 Piece/Pieces
$8896-15 Piece/Pieces
$869≥16Piece/Pieces
| Jenis pembayaran: | Western Union,D/P,D/A,T/T |
| Inkoterm: | FOB |
| Transportasi: | Ocean,Land |
| Pelabuhan: | SHANGHAI,TIANJING,QINGDAO |
Merek: Lundi
Applicable Industries: Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company
Showroom Location: None
Condition: New
Brand Name: LunDI
Power Souce: Ac Motor
Min. Lifting Height: 90mm
Overall Dimensions: 1860 l1(mm)
Warranty: 1 Year
Machinery Test Report: Provided
Video Outgoing-inspection: Provided
Warranty Of Core Components: 1 Year
Komponen Inti: Bejana tekan, Motor, lain, Bantalan, Gigi, Pompa, Gearbox, Mesin
Model: BDD15
Working Mode: Semi-Electric
Weight(with Battery): 380kg
Lift Height: 1600mm
Overall Length: 1860mm
Overall Width: 800mm
Drivering Control System: AC
Masa Garansi: 1 tahun
After Warranty Service: Online Support
Local Service Location: None
After-sales Service Provided: Online Support
Industri Yang Berlaku: Hotel, Toko Garmen, Toko Bahan Bangunan, Energi & Pertambangan, Toko Makanan & Minuman, Bengkel Mesin, Pabrik Manufaktur, Perusahaan periklanan, Peternakan, Penggunaan Rumah, Eceran
Layanan Di Luar Garansi: Dukungan teknis video
Status: Baru
Tempat Asal: Cina
Sumber Daya Listrik: Motor AC
Laporan Uji Mekanis: Disediakan
Inspeksi Pabrik Video: Disediakan
Jenis Pemasaran: Produk Biasa
Masa Garansi Komponen Inti: 1 tahun
Place Of Origin: Jiangsu, China
Fork Length: 1100 mm
Fork Width: 690 mm
Fork Width: 320-1030mm
Certification: CE, CE
| Menjual unit | : | Piece/Pieces |
| Tipe paket | : | Film yang dibungkus, ekspor palet standar atau kotak kayu. Metode pengemasan spesifik dapat dibahas. |
| Contoh pada gamba | : |
|
|
Model |
|
BDD15 |
|
Working mode |
|
Electric |
|
Driving mode |
|
Walkie |
|
Rated load |
Q (kg) |
1500 |
|
Load centre distance |
c (mm) |
500 |
|
Front suspension |
x (mm) |
745 |
|
Wheel spacing |
Y (mm) |
1200 |
|
Weight (with battery) |
kg |
380 |
|
Wheels |
|
nylon |
|
Wheel size, front wheel |
|
Φ180*50 |
|
Wheel size, rear wheel |
|
Φ80×70 |
|
Wheel, front and rear number (x = drive wheel) |
|
2/2 |
|
Front wheel |
b10(mm) |
690 |
|
Rear wheel |
b11(mm) |
410/525 |
|
Lift height |
h1(mm) |
1600 |
|
Height of door frame retracted |
h3(mm) |
2090 |
|
Maximum height of gantry during operation |
h4(mm) |
2100 |
|
Lower height |
h13(mm) |
90 |
|
Overall length |
l1(mm) |
1860 |
|
Length of fork |
l2(mm) |
1100 |
|
Overall width |
b1(mm) |
800 |
|
Fork size |
S/e/l (mm) |
50×160×1100 |
|
Fork width |
b5(mm) |
320-1030 |
|
Distance center off clearance |
m2(mm) |
40 |
|
Channel width, tray 1000 x1200(1200 cross fork placement) |
Ast(mm) |
2305 |
|
Channel width, pallet 800 x1200(1200 placed along fork) |
Ast(mm) |
2258 |
|
Turning radius |
Wa(mm) |
1425 |
|
Speed up, full load/ no load |
m/s |
0.08/0.1 |
|
Drop speed, full load/ no load |
m/s |
0.15/0.12 |
|
Driving brake |
|
Mechanical braking |
|
Lift motor power |
kW |
2.2 |
|
Battery voltage/ rated capacity |
V/Ah |
12/120 |
|
Battery weight |
Kg |
43 |
|
Driver's Ear Noise Level DIN12053 |
dB (A) |
≤70 |
Jiangsu Lundi Forklif Co.ltd. adalah peralatan logistik R&D dan pemasok produksi. Perusahaan memiliki teknologi tinggi
T1: Apakah Anda sebuah pabrik?
A1: Tentu saja.
Q2. Bagaimana lona yang diperlukan untuk mengeksekusi myorder?
A2. Tolong beri tahu kami jumlah dan jumlah model produk yang akan Anda pesan. Sehingga wewigiveyouadetaiedschedule
T3. Apakah Anda menawarkan desain khusus?
A3.Custom Desiqn pasti tersedia. Kami memiliki pengalaman yang sangat kaya dalam menyesuaikan forklift.
T4: Bagaimana dengan kebijakan sampel?
A4 Kami dapat menerima pesanan sampel untuk kualitas pengujian. Tetapi sampel dan biaya ekspres harus ada di akun pelanggan
T5: Bagaimana dengan waktu pengiriman?
A5: Biasanya waktu penghasil lundi adalah 15-20 hari kerja setelah kami menerima pembayaran lanjutan
Untuk beberapa produk standar memiliki stok dan dapat dibatalkan
T6: Apa istilah pembayaran Anda?
A6: T/T atau L/C, jika Anda menginginkan cara lain, silakan hubungi kami.
T7: Mayivisit perusahaan Anda?
A7. Kami selalu senang melayani Anda pabrik kami terletak di provinsi Taizhoujiangsu. Ada penerbangan internasional di dekatnya dan lalu lintas berkembang dengan baik.
