$72001-3 Piece/Pieces
$71804-9 Piece/Pieces
$7100≥10Piece/Pieces
| Jenis pembayaran: | D/A,D/P,T/T,Western Union |
| Inkoterm: | FOB,EXW |
| Transportasi: | Ocean,Land |
| Pelabuhan: | SHANGHAI,QINGDAO,TIANJING |
Merek: Lundi
Industri Yang Berlaku: Hotel, toko garmen, toko bahan bangunan, toko perbaikan mesin, pabrik manufaktur, pabrik makanan & minuman, peternakan, ritel, toko makanan, toko cetak, pekerjaan konstruksi, energi & pertambangan, toko makanan & minuman, perusahaan periklanan,, Hotel, Toko Garmen, Toko Bahan Bangunan, Bengkel Mesin, Pabrik Manufaktur, Peternakan, Penggunaan Rumah, Eceran, Perusahaan periklanan, Energi & Pertambangan, Toko Makanan & Minuman
Lokasi Showroom: Tidak ada
Kondisi: Baru
Nama Merk: Lundi
Power Souce: Motor AC
Min. Tinggi Pengangkat: 35mm
Dimensi Keseluruhan: 120/35/1070 s/e/l (mm)
Jaminan: 1 tahun
Laporan Tes Mesin: Asalkan
Video Keluar-inspeksi: Asalkan
Garansi Komponen Inti: 1 tahun
Komponen Inti: Bejana tekan, Motor, lain, Bantalan, Gigi, Pompa, Gearbox, Mesin
Model: CPD-S15
Mode Drive: Listrik
Berat (dengan Baterai): 1750-1880kg
Tinggi Angkat: 1600mm
Panjang Keseluruhan: 3100mm
Lebar Keseluruhan: 880mm
Sistem Kontrol Pengemudi: Ac
Masa Garansi: 1 tahun
Setelah Layanan Garansi: Dukungan online
Lokasi Layanan Lokal: Tidak ada
Layanan Purna Jual Disediakan: Dukungan online
Layanan Di Luar Garansi: Dukungan teknis video
Status: Baru
Tempat Asal: Cina, Jiangsu, Cina
Sumber Daya Listrik: Motor AC
Laporan Uji Mekanis: Disediakan
Inspeksi Pabrik Video: Disediakan
Jenis Pemasaran: Produk Biasa
Masa Garansi Komponen Inti: 1 tahun
Panjang Garpu: 1070mm
Lebar Garpu: 200 ~ 660 mm, 200-660mm
Sertifikasi: CE, CE
| Menjual unit | : | Piece/Pieces |
| Tipe paket | : | Film yang dibungkus, ekspor palet standar atau kotak kayu. Metode pengemasan spesifik dapat dibahas. |
| Contoh pada gamba | : |
|
The file is encrypted. Please fill in the following information to continue accessing it
Berdiri di atas penumpuk palet
Selama pengoperasian penumpuk semua-listrik, jangan keliru sakelar arah "maju, terbalik" sebagai sakelar kemudi. Jangan tekan pedal rem sepanjang jalan kecuali Anda perlu melambat dengan tajam. During the operation of the vehicle, when it is found that the battery power is insufficient (which can be obtained through the electricity meter, the power loss indicator light and other alarm devices), the battery should be charged as soon as possible to prevent the Baterai karena terlalu banyak dibatalkan.
| Model | CPD-S20 | |
| Drive mode | Electric (battery) | |
| Driving mode | Stand by | |
| Rated load | Q (kg) | 2000 |
| Load centre distance | c (mm) | 500 |
| Wheel spacing | Y (mm) | 1680 |
| Weight (with battery) | kg | 1750-1880 |
| Wheels (rubber wheels, high elastomers, air tyres, polyamine ester wheels) | Polyamine ester wheel | |
| Wheel size, front wheel | mm | Φ250×80 |
| Wheel size, rear wheel | mm | Φ200X80 |
| Wheel, front and rear number (x = drive wheel) | x/2 1 | |
| Rear wheel | b11(mm) | 780 |
| Lift height | h3(mm) | 4500 |
| Height of door frame lowered | h1(mm) | 2090 |
| Maximum vehicle height during operation | h4(mm) | 5090 |
| Lower height | h13(mm) | 35 |
| Overall length | l1(mm) | 3100 |
| Overall width | b1(mm) | 880 |
| Fork size | S/e/l (mm) | 120/35/1070 |
| Fork width | b5(mm) | 200~660 |
| Minimum clearance from ground | m2(mm) | 50~110 |
| Channel width, tray 1000 x1200(1200 cross fork placement) | Ast(mm) | 3300 |
| Channel width, pallet 800 x1200(1200 placed along fork) | Ast(mm) | 3280 |
| Turning radius | Wa(mm) | 1510 |
| Speed, full/no load | Km/h | 4.5/5.2 |
| Speed up, full load/ no load | m/s | 0-0.12/0-0.2 |
| Drop speed, full load/ no load | m/s | 0-0.2/0-0.18(adjustable) |
| Climbing capacity, loading/unloading | % | May 8 |
| Driving brake | Electromagnetic - regenerative braking | |
| Drive motor power | kW | 1.5(AC) |
| Lift motor power | kW | 2.2 |
| Battery voltage/ rated capacity | V/Ah | 24V /130A/210A /24 A 0 |
| Driver's Ear Noise Level DIN12053 | dB (A) |
≤70 |
| Model | CPD-S20 | |
| Drive mode | Electric (battery) | |
| Driving mode | Stand by | |
| Rated load | Q (kg) | 2000 |
| Load centre distance | c (mm) | 500 |
| Wheel spacing | Y (mm) | 1680 |
| Weight (with battery) | kg | 1750-1880 |
| Wheels (rubber wheels, high elastomers, air tyres, polyamine ester wheels) | Polyamine ester wheel | |
| Wheel size, front wheel | mm | Φ250×80 |
| Wheel size, rear wheel | mm | Φ200X80 |
| Wheel, front and rear number (x = drive wheel) | x/2 1 | |
| Rear wheel | b11(mm) | 780 |
| Lift height | h3(mm) | 4500 |
| Height of door frame lowered | h1(mm) | 2090 |
| Maximum vehicle height during operation | h4(mm) | 5090 |
| Lower height | h13(mm) | 35 |
| Overall length | l1(mm) | 3100 |
| Overall width | b1(mm) | 880 |
| Fork size | S/e/l (mm) | 120/35/1070 |
| Fork width | b5(mm) | 200~660 |
| Minimum clearance from ground | m2(mm) | 50~110 |
| Channel width, tray 1000 x1200(1200 cross fork placement) | Ast(mm) | 3300 |
| Channel width, pallet 800 x1200(1200 placed along fork) | Ast(mm) | 3280 |
| Turning radius | Wa(mm) | 1510 |
| Speed, full/no load | Km/h | 4.5/5.2 |
| Speed up, full load/ no load | m/s | 0-0.12/0-0.2 |
| Drop speed, full load/ no load | m/s | 0-0.2/0-0.18(adjustable) |
| Climbing capacity, loading/unloading | % | May 8 |
| Driving brake | Electromagnetic - regenerative braking | |
| Drive motor power | kW | 1.5(AC) |
| Lift motor power | kW | 2.2 |
| Battery voltage/ rated capacity | V/Ah | 24V /130A/210A /24 A 0 |
| Driver's Ear Noise Level DIN12053 | dB (A) |
≤70 |
T1: Apakah Anda sebuah pabrik?
A1: Tentu saja.
Q2. Bagaimana lona yang diperlukan untuk mengeksekusi myorder?
A2. Tolong beri tahu kami jumlah dan jumlah model produk yang akan Anda pesan. Sehingga wewigiveyouadetaiedschedule
T3. Apakah Anda menawarkan desain khusus?
A3.Custom Desiqn pasti tersedia. Kami memiliki pengalaman yang sangat kaya dalam menyesuaikan forklift.
T4: Bagaimana dengan kebijakan sampel?
A4 Kami dapat menerima pesanan sampel untuk kualitas pengujian. Tetapi sampel dan biaya ekspres harus ada di akun pelanggan
T5: Bagaimana dengan waktu pengiriman?
A5: Biasanya waktu penghasil lundi adalah 15-20 hari kerja setelah kami menerima pembayaran lanjutan
Untuk beberapa produk standar memiliki stok dan dapat dibatalkan
T6: Apa istilah pembayaran Anda?
A6: T/T atau L/C, jika Anda menginginkan cara lain, silakan hubungi kami.
T7: Mayivisit perusahaan Anda?
A7. Kami selalu senang melayani Anda pabrik kami terletak di provinsi Taizhoujiangsu. Ada penerbangan internasional di dekatnya dan lalu lintas berkembang dengan baik.
